INJORA INJS11 Servo with Brass Servo Mount & Horn for 1/18 Redcat Ascent-18

INJORA High Voltage Large Torque Metal Gear Digital Micro Coreless Servo for 1/18 RC Crawler Redcat Ascent-18

Compatible with:

• 1/18 Redcat Ascent-18

• 1/18 Redcat Ascent-18 Brushless

• 1/18 Redcat Ascent-18 Scout II

• 1/18 Redcat Ascent-18 Scout II Brushless

• 1/18 Redcat Ascent-18 Apex

Features:

• Two-position adjustable designed servo mount

• Provide extra weight and lower the centre of gravity

• Easy to install, just replace the stock plastic parts

• High quality CNC machined brass, corrosion resistant and durable

• Adds stylish, unique and premium touch to your vehicle's appearance

Servo Specifications:

• Part Number: INJS11

• Operating Voltage: 6V-8.4V

• Torque(6V): 8kg-cm/111oz-in

• Speed(6V): 0.106"/60°

• Torque(7.4V): 9.5kg-cm/132oz-in

• Speed(7.4V): 0.085"/60°

• Torque(8.4V): 11kg-cm/153oz-in

• Speed(8.4V): 0.074"/60°

• RC Angle: 90°±5

• 500-2500μs Angle: 180°± 5

• Motor: Coreless

• Gears: Stainless Steel

• Spline: Φ4.9 Mini 25T

• Bearing: 2BB

• Size: 32*12*27mm

• Weight: 21g

Servo Mount Specifications:

• Part Number: ASC18-13

• Material: Brass

• Weight: 10g (0.022lb)

Servo Horn Specifications:

• Material: Brass

• Weight: 2.5g

• Screw hole size: M2
